JTS

R-4

Bursting with features, the JTS R-4 has fast become the unit of choice for installers, rental companies and anybody requiring multiple wireless channels in the minimum space.  The integral power and antenna distribution make adding additional R-4 receivers easy and problem free.

RETAIL:
£895.00 inc VAT
 In Stock ( 91 Available )
SKU: 81130
EAN: 4712933610534
Commodity Code: 8518100090
Country of Origin: Taiwan

OVERVIEW
FEATURES
SPECIFICATIONS
DOWNLOADS
PRODUCT DESCRIPTION

The JTS R-4 is our newest generation of quad multi-channel wireless technology.
It features 4 channels within a 1U, 19" rack mount chassis.


The system is designed with JTS newest generation of wireless technology. To cope with the squeezed radio spectrum the system provides more compatible channels within limited bandwidth. The R-4 is a 4 channel receiver in a 1U, 19” rack mount chassis.  Antenna outputs and AC power supply are designed to be cascaded. It provides great convenience to installation.


JTS patented REMOSET feature sends all microphone data by pushing of one button. Moreover all 4 microphones can receive correspondent data at the same time after one pushing. As always JTS provides detailed and full adjustment for best audio and radio performance
KEY FEATURES
The system is designed with JTS newest generation wireless technology. To cope with the squeezed radio spectrum the system provides more compatible channels within limited bandwidth. The R-4 is a 4 channel system in a 19” one U case. Antenna outputs and AC power supply are designed to be cascaded. It provides great convenience to installation.
JTS patented REMOSET feature sends all microphone data by pushing of one button. Moreover all 4 microphones can receive correspondent data at the same time after one pushing. As always JTS provides detailed and full adjustment for best audio and radio performance
SPECIFICATIONS
Net Dimension (WxHxD):
212.3mm x 38.3mm x 144mm
Frequency Preparation:
PLL Synthesized Control
S/N Ratio:
>105dB
Display Contents:
Power On/Off, Group, Channel, Frequency Up/Down, Frequency Scan, Audio Level, Lock-on, Output Pad
Audio Output Level:
-12dB
Squelch:
Pilot Tone & Noise Mute
Operation Voltage:
12V 1A
Output Connector:
4 independent XLR outputs, and 1 Ôø?6.3mm and 1 XLR for mixed output
Carrier Frequency Range:
Options of 606.5 - 638MHz or 823 - 865MHz
AF Output Impedance:
600Ω
