The QX series of digital power amplifiers feature advanced amplifier adjustment technology to give over 95% efficiency, and stable performance at high current, low impedance conditions.
The QX4-4000 delivers 4x 1700 watts into 4 ohm
QX4-4000
Studiomaster - 4 x 1700W 1U Power Amplifier
The QX series of digital power amplifiers feature advanced amplifier adjustment technology to give over 95% efficiency, and stable performance at high current, low impedance conditions.
The QX4-4000 delivers 4x 1700 watts into 4 ohm
SKU: 130114
EAN: 5060255344309
HS Code: 8518400090
Country of Origin: China
PRODUCT DESCRIPTION
KEY FEATURES
8ohms Stereo: 4x1000watts
4ohms Stereo: 4x1700watts
2ohms Stereo: 4x2890watts
16ohm Bridged: 2x2000watts
8ohm Bridged: 2x3400watts
4ohm Bridged: 2x5780watts
SPECIFICATIONS
Number of Channels:
4
Input Impedance:
20k ohm (bal), 10k ohm (unbal)
Protection:
Low Voltage, Overload, Thermal, DC Output Protection
Net Dimensions (WXHXD):
483 x 44 x 462mm
Net Weight:
12kg
Operating Voltage:
90-250VAC, 50/60Hz
AC Mains Connector:
32A
S/N (20 HZ - 20KHZ @ 8 OHM):
> 105-112dB
Damping Factor:
(8ohm, 20Hz : 200Hz): 5000
Input Sensitivity:
41dB, 38dB, 35dB, 32dB Selectable
