Antenna Systems

The JTS Active Paddle Pack assures impeccable RF coverage over a 100 degree dispersion.

The pack includes:

2x JTS UDA-49A Active Paddles

2x JTS 10m BNC - BNC 50 Ohm Cables

*Only use active paddles where the cable run from the paddle to the receiver is greater than 5m.

The ANT-49 is an Omni directional paddle antenna whichprovides consistent reception and transmission across 470-960 MHz. It is ideal for wireless microphones, in ear-monitor systems, UHF spectrum analyzer and other UHF devices. Terminated with a BNC connector

The ANT-952 is a Half Wave Whip antenna 606-681MHz terminated with a BNC connector

The UA-960 Active antenna splitter. Perfect for operating up to four UHF PLL receivers from the JTS RU series with one pair of antennas With this device, it is not longer required to use the respective antennas and plug-in power supplies of the individual devices Frequency range: 470-960 MHz Power supply via four low-voltage outputs (4 x DC 12 V/1 A max.) Each antenna to be connected via BNC jacks. Additional connection for cascading further antenna splitters. Supplied with suitable connection cables.

The UB-900i is an Antenna booster for UHF PLL receivers.Power supply via JTS UHF PLL receivers or via active antenna splitter UA-960. DC feed-through output for cascading up to 2 x UB-900I max. Ideally suited for mobile applications, can be mounted onto microphone stand with 16 mm thread. Two are required for true adversity systems.

The UC-900RX is designed for receivers. It provides 2 x 4 antenna inputs to minimize RF dead zone on a stage or any venue. It also feature RF input ON/OFF, input attenuation from -31 to 0 dB and input signal ON/OFF control. The UC-900RX makes RF engineers’ job easy.

The UDA-49A is an Active UHF directional antenna. Designed for wireless microphone systems (reception antenna) or for wireless in-ear monitoring systems.Switchable gain (3 dB/10 dB) to avoid power loss. Power supply via JTS UHF PLL receivers or the active antenna splitter UA-960. Range of 470-960 MHz. Rejects unwanted RF signals, minimises signal loss in multipath receptions and reduces interference susceptibility. BNC connection can be mounted onto any microphone stand with a thread of 9 mm (?") or 16 mm (?") 2 x UDA-49A required for true diversity reception.

The UDA-49P is a Passive UHF directional antenna. Designed for wireless microphone systems (reception antenna) or for wireless in-ear monitoring systems, e.g. SIEM-111 from JTS (transmitting antenna) Improved reception. Range of 470-960 MHz. Rejects unwanted RF signals, minimises signal loss in multipath receptions and reduces interference susceptibility. BNC connection can be mounted onto any microphone stand with a thread of 9 mm (?") or 16 mm (?") 2 x UDA-49P required for true diversity reception.

The USP-900 is a Passive UHF antenna splitter/UHFcombiner. Perfect or minimising the amount of antennas for wireless receiver systems or transmission systems. Splits one antenna input signal to two antenna output signals. DC suppression.
