AX 800

Tough, reliable, genuinly powerful the AX 800 offers this and is ideal for live sound reinforcement speaker systems in clubs, discos, piano bar, conference halls, houses of worship, sports arenas, schools, theatres, mobile DJ use, recording studio monitors and foreground music reproduction.
RETAIL:
£359.00 inc VAT
 In Stock ( 15 Available )
SKU: 39694
EAN: 8034138396942
Commodity Code: 85185000
Country of Origin: China

OVERVIEW
FEATURES
SPECIFICATIONS
DOWNLOADS
PRODUCT DESCRIPTION

2 Ch. Power Amp - 2x400Wrms (4ohm) - 800Wrms (8ohm bridge)

Suitable applications:
Amplification for live sound reinforcement speaker systems in clubs, discos, piano bar, conference halls, houses of worship, sports arenas, schools, theatres, mobile D.J. use, recording studio monitors, foreground music reproduction, etc.



Tour tough built, sleek design, impressive specs, excellent cost per watt performance, efficient under any application. With these credentials, FBT proudly presents the new AX series of power amplifiers, the perfect power mates for sound reinforcement speaker systems. The AX series consists in four 2HU rack mount models, from 800 to 3000 watts, all designed with sophisticated power amp circuits for improved quality, stability and reliability, all equipped with Stereo-Parallel-Bridge operation mode, dB sensitivity switch (26-29-32dB), limiter, ground lift, XLR/Jack inputs (plus extra RCA input on AX 800), Speakon/Binding posts outputs.

KEY FEATURES
Both channel driven 8 ohm 1% THD Continous/impulsive: 230/250W
Both channel driven 4 ohm 1% THD Continous/impulsive: 350/400W
Bridge 8ohm 1% THD: 700/800W
Input impedance: 20Kbalanced
Signal to noise ratio S/N: >100dB
Total harmonic dist. (1kHz-4ohm): < 0.03%
Frequency response: 20Hz-40kHz -6dB
Damping Factor: > 400
Class: AB
Maximum power consuption: 1000VA
Power supply voltage: 120 or 230 Vac 50/60Hz
Protections: Short circuit / thermal
Connectors: IN: XLR/Jack - Out: Speakon/Binding post


SPECIFICATIONS
Net Dimension (WxHxD):
482 x 88 x 290mm
